Потолочник Cariboni group M48 AREA

A versatile, modular, high performance, ceiling-mounted LED system, ideal for lighting retail spaces, industrial areas, arcades and covered car parks.‎ The number of LED modules may vary from one to three depending on the level of performance required.‎ Option of replacing any of the LED modules without having to make any manual electrical disconnections as there is no wiring between the modules.‎ Option of fixing the luminaire directly to the busbar using the bracket kit supplied with all the busbar systems on the market.‎ A ceiling mounting suspension system with cables and brackets is available.‎ Connecting the system to a line is quick, easy and toolfree as the product does not need to be opened.‎ The product is supplied with a DALI dimmable system and emergency system.‎ The emergency system operates when connected to a centralised switching system between the 230V line and a DC voltage line, guaranteeing a minimum flux of 15% and a maximum flux of 60%.‎ Colours: grey RAL 9006 or white RAL 9003.‎ Optics: square large beam QU-D, rectangular asymmetric large beam RE-AD and rectangular focused RE-C.‎ CRI (Colour Rendering Index): Ra ≥ 70.‎ Average LED lifetime 80,[email protected]@Ta25°C TM21.‎ Compatible control systems: movement sensors and presence and light detectors, controlled by DALI protocol.‎ The two and three module versions can be powered with separate drivers.‎ Luminaire with no photobiological risk (EXEMPT GROUP) in compliance with EN 62471:2008 and the successive IEC/TR 62471:2009.‎ Classification: CUT OFF.‎

Nominal voltage 230 V 50 Hz
Insulation class Class II
Protection level IP IP66
Protection against impact IK08
Colour temperature 4000 K
Weight 14.‎00 kg, 18.‎50 kg, 7.‎60 kg
Labels and Certifications ENEC / CE
Warranty 5 years for LED fittings
